Lascar | DPM 500

3 ½ Digit LCD Voltmeter

Overview

This compact panel meter features a 3½ digit LCD with 12.5mm (0.5”) digit height, annunciators and a low-profile bezel for mounting. With a 200mV d.c. full scale reading, auto-zero and auto-polarity this meter plugs directly into a 40-way DIL socket or can be panel mounted using the snap-in bezel and window supplied. The DPM 500 is a popular part and is suitable for new designs.

Specification

Accuracy (overall error)
0.05 0.1 % (±1 count)
Operating temperature
0 to 50 °C (32 to 122 °F)
Sample rate
3 samples/sec
Supply voltage
7.5 to 14 V d.c.
Supply current
150 uA

Application Info

The DPM 500 is suitable for a wide variety of applications.  These include:

  • Precision Instrumentation Systems
  • Power Supply Monitoring
  • Hand held instruments
  • Panel-Mount Indication
  • Automotive Projects
